Position Sensor Leader

Counts to 44-Turns in a Compact 22 mm Package

The MZ1-2200 magnetic multi-turn sensor counts up to 44 turns (15,840°) in a 22 mm diameter housing and remembers shaft positions even when power is lost. A true power-on sensor, when power is restored, the correct turn count and angle are held and output.

MZ1-2200 multi-turn sensors provide the level of reliability and accuracy sought in demanding applications like:

• Off-highway vehicle steering
• Vehicle driveline
• Agricultural machinery
• Construction equipment / vehicles
• Gate drives
• Medical equipment

The MZ1-2200 is based on Novotechnik’s patented non-contact multi-turn for absolute 15,840° (44 turns) measurement. This wear-free technology combines advanced capabilities with mechanical simplicity in a very compact and sturdy housing to provide for longer life and lower cost than optical encoders.

MZ1-2200 Specifications:

• Absolute multi-turn
• Up to 44 turns
• 16 bit resolution
• Repeatability of ≤ ±0.1°
• Independent linearity of ≤ ±1°
• Housing OD = 22 mm
• Incursion protection options of IP50 or IP55
• No gears, no optics, no batteries
• Interface is CANopen

MZ1-2200

New novoturn™ technology by Novotechnik provides engineers with the following unique benefits.

▶ No gears, non-contact sensing means long life

▶ Small size for easy integration

▶ Works during power loss for over five years

▶ Maintains accuracy during power loss

▶ Continues to work upon power restoration

▶ Combined counting and position sensing in one part provides accuracy and flexibility

▶ High accuracy with no optics means lower cost
