Position Sensor Leader

TP1 HP Series Permanent In-Cylinder Position Sensing

Every one of Novotechnik’s TP1 HP Series of magnetostrictive position sensors come with one vital thing that’s not in the specs and is equally important – unmatched technical support.

Our engineers work with you before you even decide to select our part to discuss your application and answer your questions. If you choose the TP1 HP Series, we’ll support you in three ways:

1) work with you through your design process to help you make the best choice for your application and get predictable results

2) help you get the most from our TP1 HP Series to meet your applications requirements

3) continued support, should you need it, even after the sale and your production starts

Novotechnik’s TP1 HP Series of hydraulic and pneumatic sensors work by installing a permanent magnetic pickup inside your application’s cylinder while the TP1 HP Series sensor mounts outside the cylinder and accurately tracks the position of the pickup. TP1 HP Series works out of the box without need for any zero or span adjustments to meet specs. Analog and digital output versions are standard.

Key specs:

• Shock to 100 g
• Vibration to 20 g
• Sealed to IP 68
• Absolute linearity to ≤ ± 25 μm
• Unlimited mechanical life
• 0.2 to 13.9 foot stroke lengths
