360º Contactless Angle Measurement with 12-bit Resolution

Novotechnik’s VX22 is among the smallest 12-bit non-contacting rotary angle sensors – with less than 0.88” diameter x 1.2” depth. The sensor utilizes Novotechnik’s VERT-X®-Hall Technology and provides absolute measurement for angles up to 360º. Plus, the VX22 sensor will hold the current angle measurement in the event of a power spike or failure. Standard current and voltage output options are available.

  • Life >360 million movements
  • Resolution ±0.09°
  • Accuracy ±0.35°
  • Programmable output
  • Withstands high EMC levels
  • Wide temperature range: -40 to 125°C
  • Sealed to IP 54, IP 67 optional
